Here are photos from some projects we’ve worked on (hover for description and click to enlarge):
A PLC-based solution for automating multiple generators on an off-grid ranch
Custom Delrin mounting adapter for marine multi-band antenna
Custom machined gripper for university automation project
A lot of 100 parts returned from anodizing, ready for assembly and final inspection
Custom second operation fixture to hold a 5-axis part for an industrial scientific application
Machined billet fire engine siren cover
CNC turned spacers from tool steel
Nut for shop tooling turned from 17-4 PH stainless steel
Coolant Bypass Part Production
Engine Coolant Part Production
A custom engraved sign for a friend
A prototype box for a set of dice
Custom stainless diesel tank cap
Engine studs for non-standard thread
Initial facing pass on a large part for a scientific application
Checking machined aluminum fixture plate for flatness before next operation
Machined aluminum blocks for a laboratory dry bath heater which transfer efficiently heat to small test tubes
Weatherproof Inverter Enclosure
Fiber optic adapter for laser module
A custom lightweight wrench for Seattle Mountain Rescue for tightening quick links in the field
Prototype parts comparing tumbled + anodized, anodized, and raw machined finish
Mounting plate for a motor and belt drive
A piece of 'shop art' we put together from scrap metal to liven up our hallway
Custom route tags for a climbing gym
Stainless Tray for Research
Prototype soft jaw for self-centering vise
Installing a spring plunger in a finished part
Formula Racecar Steering Knuckle
Formula Racecar Suspension Rocker
Pin for hanging planter design
Machined pulley spacer for aftermarket marine alternator
Turning raw bushings to press-fit size
Turned 304 stainless pins for custom fabricated marine davit crane
Machined axles for custom downrigger mount
Custom pins for an emergency marine steering linkage repair
Replacement diesel engine throttle linkage
Turned UHMW bushings for a winch axle
Reverse-engineered weld-on threaded bungs for refrigeration system
Machined ears for a welded winch assembly
Large sideplates machined for a winch drum
Custom shaft seal for an auger assembly
Prototype machined aluminum motorcycle footpeg
Testing the custom quick link wrench
Front view of unit showing pressure gauge
Side view of unit showing trigger button
Graduated scale for height setting
Blast TBI research device
Custom cuvette heater block
Custom spring-loaded end effector for biotech robotics application
Schematic showing linear guideway layout to support two independent subjects
Block for stabilizing pipette temperatures
Machined aluminum wax bath to replace a molded plastic version
